XRC440 Series Adhesive-lined Lead-free Rubber

Lead-free x-ray protective material with Pressure Sensitive Adhesive backing. General purpose use for x-ray cabinets, medical and general NDT radiation shielding. Lead-free vinyl skin for safer handling and improved strength.

Use for protection from gamma radiation or x-ray tubes.
- Lead equivalent thicknesses from 0.125mm Pb to 0.5mm Pb.
- Sheets and roll sizes up to 2 ft or 600mm width.

Adhesive Properties

- Special acrylic adhesive with excellent chemical resistance and bond strength even at elevated temperatures.
- Long Term Temperature Resistance -40 °C to 120 °C
- Bonds well to a wide variety of plastics, powder coatings and metals.

Peel Adhesion by ASTM D3330:
- 16.4 N/cm Stainless Steel
- 15.8 N/cm Painted Metal
- 9.3 N/cm ABS
- 9.8 N/cm Polyvinyl chloride (PVC)
- 10.0 N/cm Aluminum

Download Technical Data Sheet for

Product Options and Formats

All product is made to order to ensure quality of the adhesive material.  Standard roll sizes are 600mm by 1200mm (2 ft x 4 ft) for 1/32" LE and 1/16" LE, and 300mm by 1200mm (1 ft x 4 ft) for 5/64" LE and 1/8" LE.  Product is available with larger roll sizes, precut panels, and custom cut shapes.

Lead-Free Certification

This product is compliant with Directive 2011/65/EU of the European Parliament and the Council of 8 June 2011 for Restrictions of Hazardous Substances (RoHS) and that the maximum concentration values by weight for lead, hexavalent chromium, cadmium, mercury, polybrominated biphenyls and polybrominated diphenylethers are in compliance.
